Product Overview
Introducing the BatteryEVO 72V 22 kWh LiFePO4 KONG Battery—a top-tier solution for building a robust solar or off-grid power system.
Designed for durability in demanding environments, the KONG battery is equipped with an advanced Battery Management System (BMS) that optimizes performance, especially in cold weather. It features high-quality LiFePO4 cells and comes with durable caster wheels for easy mobility and flexible storage placement.
Setting a new benchmark for BMS protection, the KONG delivers consistent power while maintaining top safety standards. Its LED Smart Display provides real-time insights into battery health and key operational metrics, ensuring efficient energy management.
Enhance your power system with the KONG—one of the most reliable and high-performance options available for off-grid and residential energy storage. Backed by a 10-year warranty, the 72V KONG is the ideal choice for those seeking a significant upgrade.
Key Benefits
✅ 200% - Twice the power of standard batteries
✅ 4X - Longer cycle life
✅ 1/3 - Lighter and more compact
✅ 100% - Safe & reliable
Technical Specifications
-
SKU: EVO-KONG-72220-G1
-
Model Name: KONG
-
System Voltage: 72V
-
Nominal Voltage: 76.8V
-
Chemistry: LiFePO4 (LFP)
-
Capacity: 22kWh / 280Ah
-
Charging Voltage: 84V - 87.6V
-
Maximum Charge Voltage: 88.8V
-
Operating Voltage Range: 66.5V - 87.6V
-
Recommended Low Voltage Cutoff: 66.5V - 72V
-
Cell Configuration: 24S1P
-
Max Continuous Discharge Current: 200A
-
Max Continuous Power Output: 15,360W
-
Max Discharge Peak Current: 300A (5 seconds)
-
Max Charge Current: 200A
-
Temperature Ranges:
-
Charging: 0°C (32°F) to 55°C (131°F)
-
Discharging: -20°C (-4°F) to 55°C (131°F)
-
Optimal Discharge: 15°C (59°F) to 35°C (95°F)
-
Storage: -5°C (23°F) to 35°C (95°F) (up to 6 months)
-
Weight: 452 lbs (205.02 kg)
-
Dimensions:
-
Depth: 13.4 in (340 mm)
-
Width: 23.6 in (600 mm)
-
Height: 43.5 in (1105 mm)
-
Safety Features:
- 300A Fuse
- Advanced BMS protection (Over/Under Voltage, Overcurrent, and Temperature Protection)
-
Max Parallel Connections: Up to 8 units
